■ Built-in socket for a 2.5” SATA SSD for space saving and superior drive performance
■ Hybrid (HyperDuo) enables 80% of SSD performance at one-third the cost
Note: HyperDuo automatic storage tiering is only compatible with Windows XP, Vista, 7 and 8. This feature is not fully supported in the Server OSes
■ Hardware RAID (RAID 0, 1 & 10) to offload the host CPU for max performance
Supports Port Multiplier FIS-based and Native Command Queuing (NCQ)
Note: Only one Port Multiplier is supported at any one time. Supports up to 4 drives connected via Port Multiplier plus 3 single drives for 7 drives total
■ Supports TRIM to extend the life of SSDs for maximum durability
■ HyperDuo mode supports Safe mode and Capacity mode
■ 48-bit LBA mode with support up to 4TB hard disk capacity
■ Works with the latest 6Gb/s SATA HDDs and backwards compatible with 3Gb/s and 1.5Gb/s HDDs
■ Adds one M.2 PCIe SSD (M key) to your PCIe equipped desktop computer to dramatically increase speed and performance
Note: This adapter is not compatible with B key M.2 PCIe SSDs or B key M.2 SATA SSDs
■ Accommodates 2230, 2242, 2260 and 2280 form factor M.2 SSDs (NVMe or AHCI) via multiple mounting holes
■ Supports PCIe 3.0 motherboard and backward compatible with PCIe 1.0 and PCIe 2.0
■ Supports PCIe x4 bus slot and compatible with x8 / x16 bus slot
■ Built-in LEDs indicate power and data transfer status
■ Includes both low-profile and full-profile slot brackets for flexible system chassis installation
■ No driver installation required
■ Supports RAID 0 (striping), RAID 1 (mirroring) and RAID 10 (mirror + striping) for performance and reliability
■ Thin, flexible Serial ATA cables make it easier to route inside a PC
■ Breaks the 137GB barrier! Supports various brands of large capacity Serial ATA hard drives
■ Lower pin count and voltage requirement, plus better cabling over traditional Parallel ATA make Serial ATA the controller of the future
■ Four high quality SATA cables and two dual connector SATA power cables required for RAID configuration are included
■ Two “Y” split power cables are also included to provide extra power connection
■ Solves your system's connectivity needs by adding two USB 3.0 ports and one Gigabit Ethernet port through one USB 3.0 port
■ Supports USB 3.0 data transfer rates up to 5Gbps for smooth and stable performance
■ Converts your system's Mini DisplayPort output to either HDMI or DisplayPort output
■ Supports triple display modes (Mirror, Extended, Primary) through either HDMI or DisplayPort output to various applications such as presentation or entertainment
■ Compact and lightweight design makes it easy-to-carry and the perfect on-the-go gadget
■ Compatible with many Mini DisplayPort and USB 3.0 equipped computers, laptops and tablets
■ Plug and play, no driver installation and no external power adapter required
docking station
■ PCI Express 1-lane (x1) adapter works with PCI Express slots with different lane width
■ Installs in any available PCI Express slot
■ Four high-speed 16550 UART RS-232 serial ports (9-pin) support asynchronous baud rates up to 921Kbps
■ Works as standard RS-232 port or with 5V or 12V power output for devices that require power (such as handheld scanners, table scanners, POS displays, etc.). Configurable via jumpers with silk-screened settings on PCB
■ Built-in 256-byte FIFO buffers dramatically increase data transmit/receive speed, especially under Windows multitasking environment
■ Spare enhanced low profile bracket is included to work in low profile chassis
■ Onboard power connector to provide reliable power source for devices that require power
■ 4-layer PCB board: separate layers for data and grounding. Greatly reduces signal noise and loss. Delivers more reliable high-speed data transfers
■ Designed to add two 9-pin RS-232 serial ports to PCIe enabled desktop computers
■ Two high-speed serial ports supporting asynchronous baud rates of up to 921.6Kb/s
■ Built-in 128-byte buffers dramatically increase data transfer rates especially under Windows multi-tasking environment
■ Works as either a standard RS-232 port or with a 5V/12V power output for devices that require power such as handheld scanners, table scanners, POS displays and many more
■ Dual profile works in any available PCI Express slots of different lane widths
■ Installs in standard height or low profile chassis with included low profile bracket
■ Adds 2 (9-pin) RS-232 serial ports to your PCI enabled system
■ Can be installed in 32-/64-bit, 3.3V/5V PCI and PCI-X slots
■ Works with modems, PDAs, and high-speed serial devices
■ Full support for DOS and Windows based software
■ Adds four 9-pin RS-232 16550 UART serial ports to your PCI enabled system
■ Supports data transfer rate up to 230Kb/s
■ Supports up to 256-byte FIFO buffer
■ Supports 32-/64-bit, 3.3V/5V PCI and PCI-X slots
■ Four high-speed 16550 UART serial ports (9-pin) support data rate up to 230Kb/s
■ Will work as standard RS-232 port or with 5V or 12V power output for devices that require power (such as handheld scanners, table scanners, POS displays, etc.). Configurable via jumpers with silk-screened settings on PCB
■ Designed to add two 9-pin RS-232 serial ports to your PCI enabled desktop computer
■ Two high-speed 16950 UART serial ports support data transfer rates up to 920Kb/s
■ Built-in 128-byte FIFO buffers dramatically increase data transmit and receive speeds especially under Windows multitasking environment
■ Works as standard RS-232 serial ports to support serial devices including ISDN terminal adapters, PDAs, digital cameras and label printers
■ Can be configured with a 5V or 12V power output for devices that require power such as handheld scanners, table scanners, POS displays and many more
■ Supports serial port data transfer rates up to 921Kb/s
■ Built-in 15KVDC ESD serial interface protection
■ Supports 3.3V and 5V PCI and PCI-X slots
■ Built-in 256-Byte FIFO buffer
■ Installs in standard height or low profile chassis with included brackets
■ Universal PCI card design that works in 32-/64-bit, 3.3V/5V PCI and PCI-X slots
■ Provides 2 RS-232 16550 UART serial ports with 32-byte FIFO buffers
■ Installs in standard height or low profile chassis with included brackets
■ Can be configured for 5V or 12V power output
■ Supports 32-/64-bit, 3.3V/5V PCI and PCI-X slots
■ Four high-speed 16550 UART serial ports (9-pin) support data rate up to 230 Kbps
■ Dual Profile design to work in standard-height and low-profile chassis with the included brackets
■ Will work as standard RS-232 serial port or with 5V or 12V power output for devices that require power (such as hand held scanners, table scanners, POS displays, etc.). Configurable via jumpers with silk-screened settings on PCB.
■ Designed to add one DB 25-pin parallel port to your PCIe enabled desktop computer
■ ECP/EPP parallel port delivers data transfer rates of up to 1.5MB/s
■ Supports ECP, EPP, SPP parallel port modes
■ Dual profile works in any available PCI Express slots of different lane widths
■ Installs in standard height or low profile chassis with included brackets
■ Easily add one high-speed parallel port (25-pin) to your PCI Express desktop system
■ Dual-profile PCB and brackets support standard height and low profile desktop systems
■ Full support for Windows-based software and applications
■ Adds one ECP/EPP parallel port to your PCI enabled desktop computer
■ ECP/EPP parallel port delivers data transfer rates of up to 1.5MB/s
■ Installs in standard height or low profile chassis with included spare enhanced low profile bracket
■ Adds 2 ECP/EPP parallel ports to your PCI enabled system
■ Can be installed in 32-/64-bit, 3.3v/5v PCI and PCI-X slot
■ Dual Profile design to install in standard height or low profile chassis with included brackets
■ PCI Express (PCIe) adapter with 1 high-speed 16950 UART serial (9-pin) and ECP/EPP parallel (DB25) port
■ Works as standard RS-232 port or with 5V or 12V power output for devices that require power (such as handheld scanners, table scanners, POS displays, etc.). Configurable via jumpers
■ Adds 2 RS-232 9-pin serial and 1 ECP/EPP parallel port to your PCIe enabled system
■ Two 16C650 UART serial ports support data rate up to 16Mbps
■ Supports ECP, EPP and Buffered SPP parallel port modes
■ Adds 2 external SATA (eSATA) 6Gb/s channels to your PCIe system
■ Supports port multiplier - up to 5 hard disks (max) on each eSATA port and up to 7 hard disks amongst the connected port multipliers. Note: The included Asmedia driver must be installed for port multiplier operation
■ Installs in standard height or low profile chassis with included brackets
■ Works with the latest 6Gb/s SATA HDDs and backwards compatible with 3Gb/s and 1.5Gb/s HDDs
